SINOTRUK Chassis Street Vacuum Sewage Type Suction Trucks Capacity 2-4cbm For Sale 2-4cbm

1.0 Units
MOQ
SINOTRUK Chassis Street Vacuum Sewage Type Suction Trucks Capacity 2-4cbm For Sale 2-4cbm
Features Gallery Product Description Request A Quote
Features
Specifications
Transmission Type: Automatic
Condition: New
Emission Standard: Euro 4
Fuel Type: Diesel
Tank Volume: 2-4cbm
车身尺寸: 5850*2100*2600mm
Horsepower: 116hp
Gross Vehicle Weight: 8000
Dimensions: 5850X2100X2600mm
GVW: 8000kg
Curb Weight: 4000kg
Chassis Brand: SINOTRUK
Wheelbase: 3360mm
Tire Quantity: 6+1 Units
Emission Level: Euro 2
Number Of Gears: 6 Forward Gears & 1 Reverse
Capacity: 2-4cbm
Fuel: Diesel
Basic Infomation
Payment & Shipping Terms
Packaging Details: Fire Truck:payment methods: varies from place to place standard export package
Supply Ability: 500 Set/Sets per Year Fire Truck
Product Description

SINOTRUK Chassis Suction-Type Street Vacuum Sewage Suction Trucks 2-4cbm Capacity for sale

Product Description
The truck uses a round tank with good pressure-bearing performance. Stainless steel tanks are optional. Adopt a water-cooled vacuum pump of the well-known brand, making double pumps in series. It has advantages such as long single continuous operation time, high absolute working pressure, large flow rate and suction power, and long suction range. The tailgate adopts an independent patented opening and closing locking device that come with a hydraulic system in well safety protection. The double insurance mechanism makes the container and the tailgate rubber strip reliably sealed, ensuring that the sewage is kept closed during the collection and transportation. The liquid level display of the sewage tank is easy to observe, easy to disassemble, and easy to clean and maintain.
Vehicle Description
Overall dimensions 5850*2100*2600mm
GVW 8000kg
Curb weight 4000kg
Chassis brand SINOTRUK
Traction type 4*2, left/right hand drive
Chassis Description
Chassis model ZZ1047D3415C145
Cab HOWO light truck,L2W-2080
Wheelbase 3360mm
Tire specification 7.50R16
Tire quantity 6+1 units
Engine Engine model YN4102QBZL
Emission level Euro 2
Displacement/output 3760ml/75kw
Horse power 116hp
Gear box Model WLY6T46
Number of gears 6 forward gears & 1 reverse
Brake system Full air brake system
Axle Front 2.4T
Rear 4.2T
Suspension Front Leaf springs
Rear Leaf springs
Fuel tanker Type Steel fuel tank, with lockable cap
Capacity 120L
FAQ



1, Q: Why should we choose you ?

    A: We are professional manufacture located in Shanghai city for trucks

        products which nearby Pudong International Airport, is easily for customer coming

        and visiting.

    B: We can export directly to overseas customer, no need to deal with trading company

         and the second price increase will not occur

    C: We have our own R&D team, production workshop, QC management team,

        international marketing team and after service team.

    D: We will provide the most professional and the best service on every business

        discussion and operation procedure.

    E: We can provide special design for different specification requirement according to

          different orders or tender documents.

    G: We have jointed ventures with Morita for 4 years, so the technology, design and

         quality are same with Morita.

    H: We have collaboration with various top enterprises of fire protection sector, Such as

         Darley, Rosenbauer, HALE, AKRON, Ekhart, etc.

    I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC.
2, Q: What's your Payment method?
    A: T/T 30% deposit, balance will be paid by T/T before delivery
    B: 100% L/C before start production
3, Q: What logistics ways we can work for shipment?
    A:We can ship fire trucks by various transportation tools

    B:We will go by sea to all main continents such as South America, Middle East, Africa,

       Oceania and Europe etc.


4, Q: What's the delivery time?

     A: 20 days delivery upon receipt of advance deposit if we have ready in stock for

         normal standard model.

     B: ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
     C: European brand chassis 9 months upon receipt of advance deposit.
5, Q: Can you provide the ISO9001 certificate or some others related?

     A: Yes. We have been exporting fire trucks for years. Rich experience for exporting to different

          countries like African market, Russia and South America. This helps us to know the importance

          of handling with various certificates.





Product Process
Certifications

Packaging & Shipping





Company Information

Shanghai Jindun is a professional fire protection enterprise,one of the largest fire protection equipment and fire fighting vehicle manufacturer.Our company owns a first-rate ultra-large modern factory, internationally advanced processing equipment, domestic and foreign sales networks and a powerful service system, gathers many top technicians and industrial experts, and has 112 types of products, including CAFS fire trucks, water tank foam trucks, rescue vehicles, gas supply vehicles and other general fire trucks.Our Company will give you best products and best service.
