Dongfeng 6x4 SK5060GXWE Heavy Duty Tanker Sewage Suction Tanker Truck

Chassis parameters

Chassis model

EQ1060TJ20D3

Chassis brand

DONGFENG

Overall dimensions

5850X1950X2080mm

Wheel base

3300mm

Front/rear wheel track

1750/1586mm

Front/rear suspension

1180/1590mm

Approach/departure angle

22/23°

Maximum speed

80km/h

Chassis Manufacturer

Dongfeng Automobile Co., Ltd

Cab

Configuration

Cab width: 1730mm, single row cab, allowable 2 passengers, power-assisted steering, camel battery (24V maintenance free), pneumatic brake system, air conditioner

Color

White, other color is optional

Engine

Model

YC4F115-30

Emission

Euro 3

Type

Vertical, in-line, four stroke, water cooling, diesel engine

Rated power

85KW /115hp,rated power speed 3200rpm

Displacement

2.659L

Bore x stroke

92x100mm

Manufacturer

Dongfeng Chaoyang Diesel Power Co. Ltd.

Tire

Size

7.00R16 Steel wire

Number

6+1 nos

Frame

188mm

Front axle

2.0T

Rear axle

4.0T

Drive form

4X2

Rated voltage

24V,DC

Transmissions

5 speed forward 1 reverse.

Steering wheel

Left hand drive

Selective configuration

Air conditioner

If there is a slight change in the chassis parameters above, please take the actual product as the standard

Vacuum sewage suction tank structure parameters

Tank dimensions

3000×1250×1250mm

Tank volume

4000L

Tank material

Carbon steel

Tank thickness

6mm

Color and Logo

Optional

China vacuum pump

Model

XD-185

RPM

950r/min

Flow

52L/s

Pressure

-90000Pa

Power

5kw

Standard configuration

Chassis, sub frame, vacuum sewage tank, oil water separator, water gas separator, hydraulic cylinder for unloading device, domestic vacuum pump, pressure gauge, suction hose, gravity flow valve, connected device, observation tube, automatic anti overflow valve, hydraulic suite, rear door hydraulic opening.
